L-05B20NJV6T

Technical Details

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Multilayer
• Material - Core:Ceramic
• Inductance:20 nH
• Tolerance:±5%
• Current Rating (Amps):200 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):-

• Q @ Freq:5 @ 100MHz
• Frequency - Self Resonant:2.1GHz
• Ratings:-
• Operating Temperature:-55°C ~ 100°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0201 (0603 Metric)
• Supplier Device Package:0201 (0603 Metric)
• Size / Dimension:0.024" L x 0.012" W (0.60mm x 0.30mm)
• Height - Seated (Max):0.013" (0.33mm)
