MLG0603P5N6HT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6NH 350MA 400 MOHM
- CategoryFixed Inductors
- Datasheet MLG0603P5N6HT000 Datasheet
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$0.01696
- 15,000$0.01696
Quote It
Technical Details
- Series:MLG-P
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Non-Magnetic
- Inductance:5.6 nH
- Tolerance:±3%
- Current Rating (Amps):350 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):400mOhm Max
- Q @ Freq:14 @ 500MHz
- Frequency - Self Resonant:4GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:500 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0201 (0603 Metric)
- Supplier Device Package:0201 (0603 Metric)
- Size / Dimension:0.024" L x 0.012" W (0.60mm x 0.30mm)
- Height - Seated (Max):0.013" (0.33mm)
