MLG1005SR20HT000

Technical Details

• Series:MLG
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Multilayer
• Material - Core:Ceramic, Non-Magnetic
• Inductance:200 nH
• Tolerance:±3%
• Current Rating (Amps):100 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):4.2Ohm Max

• Q @ Freq:8 @ 100MHz
• Frequency - Self Resonant:420MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0402 (1005 Metric)
• Supplier Device Package:0402 (1005 Metric)
• Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
• Height - Seated (Max):0.022" (0.55mm)
