AQ1059N1J-T
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 9.1NH 450MA 290 MOHM
- CategoryFixed Inductors
- Datasheet AQ1059N1J-T Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$0.02832
- 10,000$0.02832
Quote It
Technical Details
- Series:AQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:-
- Inductance:9.1 nH
- Tolerance:±5%
- Current Rating (Amps):450 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):290mOhm Max
- Q @ Freq:8 @ 100MHz
- Frequency - Self Resonant:3.4GHz
- Ratings:-
- Operating Temperature:-55°C ~ 85°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.024" W (1.00mm x 0.60mm)
- Height - Seated (Max):0.020" (0.50mm)
