LQP02TN22NJ02D
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22NH 120MA 5 OHM SMD
- CategoryFixed Inductors
- Datasheet LQP02TN22NJ02D Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$0.0288
- 20,000$0.0288
Quote It
Technical Details
- Series:LQP02
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Thick Film
- Material - Core:Non-Magnetic
- Inductance:22 nH
- Tolerance:±5%
- Current Rating (Amps):120 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):5Ohm Max
- Q @ Freq:6 @ 500MHz
- Frequency - Self Resonant:2.3GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:500 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:01005 (0402 Metric)
- Supplier Device Package:01005 (0402 Metric)
- Size / Dimension:0.016" L x 0.008" W (0.40mm x 0.20mm)
- Height - Seated (Max):0.009" (0.23mm)
