LBR2012T220M
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 100MA 1 OHM SMD
- CategoryFixed Inductors
- Datasheet LBR2012T220M Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$0.045
- 3,000$0.045
Quote It
Technical Details
- Series:LB, R Type
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):100 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1Ohm
- Q @ Freq:-
- Frequency - Self Resonant:16MHz
- Ratings:-
- Operating Temperature:-25°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
