36401E22NJ
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22NH 90MA 2.65 OHM SMD
- CategoryFixed Inductors
- Datasheet 36401E22NJ Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$0.05043
- 10,000$0.0492
Quote It
Technical Details
- Series:3640, Sigma Inductors
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Thin Film
- Material - Core:-
- Inductance:22 nH
- Tolerance:±5%
- Current Rating (Amps):90 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):2.65Ohm Max
- Q @ Freq:13 @ 500MHz
- Frequency - Self Resonant:2.8GHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:500 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.015" (0.37mm)
