LQW15AN9N5H00D
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 9.5NH 540MA 140 MOHM
- CategoryFixed Inductors
- Datasheet LQW15AN9N5H00D Datasheet
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$0.0504
- 10,000$0.0504
Quote It
Technical Details
- Series:LQW15
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:9.5 nH
- Tolerance:±3%
- Current Rating (Amps):540 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):140mOhm Max
- Q @ Freq:25 @ 250MHz
- Frequency - Self Resonant:5.5GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:-
- Size / Dimension:0.039" L x 0.024" W (1.00mm x 0.60mm)
- Height - Seated (Max):0.024" (0.60mm)
