LQP02HQ4N2B02L

Technical Details

• Series:LQP02
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Thick Film
• Material - Core:-
• Inductance:4.2 nH
• Tolerance:±0.1nH
• Current Rating (Amps):350 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):350mOhm Max

• Q @ Freq:14 @ 500MHz
• Frequency - Self Resonant:6.9GHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:500 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:01005 (0402 Metric)
• Supplier Device Package:01005 (0402 Metric)
• Size / Dimension:0.016" L x 0.008" W (0.40mm x 0.20mm)
• Height - Seated (Max):0.013" (0.32mm)
