ILSB0603ERR22K
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220NH 50MA 800 MOHM
- CategoryFixed Inductors
- Datasheet ILSB0603ERR22K Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$0.06426
- 4,000$0.06426
- 8,000$0.06069
- 12,000$0.05712
- 28,000$0.05534
- 100,000$0.05176
Quote It
Technical Details
- Series:ILSB-0603
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:220 nH
- Tolerance:±10%
- Current Rating (Amps):50 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):800mOhm Max
- Q @ Freq:15 @ 25MHz
- Frequency - Self Resonant:173MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max):0.039" (1.00mm)
