CBC2518T471M

Technical Details

• Series:CB, C Type
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:470 µH
• Tolerance:±20%
• Current Rating (Amps):70 mA
• Current - Saturation (Isat):80mA
• Shielding:Unshielded
• DC Resistance (DCR):28.6Ohm Max

• Q @ Freq:-
• Frequency - Self Resonant:3.5MHz
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:796 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1007 (2518 Metric)
• Supplier Device Package:1007 (2518 Metric)
• Size / Dimension:0.098" L x 0.071" W (2.50mm x 1.80mm)
• Height - Seated (Max):0.079" (2.00mm)
