ILSB1206ER180K
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 5MA 700 MOHM SMD
- CategoryFixed Inductors
- Datasheet ILSB1206ER180K Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$0.09639
- 3,000$0.09639
- 6,000$0.09072
- 15,000$0.08789
- 30,000$0.08506
- 75,000$0.08221
Quote It
Technical Details
- Series:ILSB-1206
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±10%
- Current Rating (Amps):5 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):700mOhm Max
- Q @ Freq:45 @ 1MHz
- Frequency - Self Resonant:21MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1206 (3216 Metric)
- Supplier Device Package:1206
- Size / Dimension:0.126" L x 0.063" W (3.20mm x 1.60mm)
- Height - Seated (Max):0.055" (1.40mm)
