CB2016T101M
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 170MA 4.5 OHM
- CategoryFixed Inductors
- Datasheet CB2016T101M Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$0.0966
- 2,000$0.0966
Quote It
Technical Details
- Series:CB
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±20%
- Current Rating (Amps):170 mA
- Current - Saturation (Isat):70mA
- Shielding:Unshielded
- DC Resistance (DCR):4.5Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:8MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.071" (1.80mm)
