L-07W5N6CV4T
Johanson Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6NH 760MA 83 MOHM
- CategoryFixed Inductors
- Datasheet L-07W5N6CV4T Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$0.10253
- 10,000$0.10253
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:5.6 nH
- Tolerance:±0.2nH
- Current Rating (Amps):760 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):83mOhm Max
- Q @ Freq:61 @ 900MHz
- Frequency - Self Resonant:5.8GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:900 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.024" (0.60mm)
