AISC-0402-8N2J-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2NH 680MA 100 MOHM
- CategoryFixed Inductors
- Datasheet AISC-0402-8N2J-T Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$0.09821
- 10,000$0.09821
- 30,000$0.09504
- 50,000$0.09187
- 100,000$0.08871
Quote It
Technical Details
- Series:AISC-0402
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:8.2 nH
- Tolerance:±5%
- Current Rating (Amps):680 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):100mOhm Max
- Q @ Freq:25 @ 250MHz
- Frequency - Self Resonant:4.4GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.047" L x 0.025" W (1.19mm x 0.64mm)
- Height - Seated (Max):0.026" (0.66mm)
