BRL3225T220M
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 470MA 690 MOHM
- CategoryFixed Inductors
- Datasheet BRL3225T220M Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$0.099
- 2,000$0.099
Quote It
Technical Details
- Series:BR, L Type
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):470 mA
- Current - Saturation (Isat):550mA
- Shielding:Unshielded
- DC Resistance (DCR):690mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:13MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.067" (1.70mm)
