MLF2012C180MTD25
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 5MA 800 MOHM SMD
- CategoryFixed Inductors
- Datasheet MLF2012C180MTD25 Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$0.11088
- 2,000$0.11088
Quote It
Technical Details
- Series:MLF
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±20%
- Current Rating (Amps):5 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):800mOhm Max
- Q @ Freq:30 @ 1MHz
- Frequency - Self Resonant:20MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
