MLF1005G2R2JT
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 30MA 1.3 OHM SMD
- CategoryFixed Inductors
- Datasheet MLF1005G2R2JT Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$0.10742
- 10,000$0.10742
Quote It
Technical Details
- Series:MLF
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±5%
- Current Rating (Amps):30 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):1.3Ohm Max
- Q @ Freq:30 @ 10MHz
- Frequency - Self Resonant:80MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:10 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.022" (0.55mm)
