LQM2MPN1R0MGHL

Technical Details

• Series:LQM2
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Multilayer
• Material - Core:Ferrite
• Inductance:1 µH
• Tolerance:±20%
• Current Rating (Amps):1.9 A
• Current - Saturation (Isat):2A
• Shielding:Shielded
• DC Resistance (DCR):80mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:60MHz
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0806 (2016 Metric)
• Supplier Device Package:0806 (2016 Metric)
• Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
• Height - Seated (Max):0.039" (1.00mm)
