IMC0603ER8N2J01
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2NH 700MA 100 MOHM
- CategoryFixed Inductors
- Datasheet IMC0603ER8N2J01 Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$0.1088
- 3,000$0.1088
- 6,000$0.1024
- 15,000$0.0992
- 30,000$0.096
- 75,000$0.0928
Quote It
Technical Details
- Series:IMC-0603-01
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:8.2 nH
- Tolerance:±5%
- Current Rating (Amps):700 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):100mOhm Max
- Q @ Freq:30 @ 250MHz
- Frequency - Self Resonant:4.6GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.041" W (1.60mm x 1.05mm)
- Height - Seated (Max):0.049" (1.25mm)
