CBC2012T220MV
TAIYO YUDEN- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 145MA 4.81 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$0.10948
Quote It
Technical Details
- Series:CB, C Type
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):145 mA
- Current - Saturation (Isat):170mA
- Shielding:Unshielded
- DC Resistance (DCR):4.81Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:16MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
