NRS5010T2R2NMGF

Technical Details

• Series:NR, S Type
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:2.2 µH
• Tolerance:±30%
• Current Rating (Amps):1.6 A
• Current - Saturation (Isat):1.5A
• Shielding:Unshielded
• DC Resistance (DCR):126mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:65MHz
• Ratings:-
• Operating Temperature:-25°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.193" L x 0.193" W (4.90mm x 4.90mm)
• Height - Seated (Max):0.039" (1.00mm)
