WCL3225-561-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 30MA 28 OHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$0.1116
Quote It
Technical Details
- Series:WCL3225
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:560 µH
- Tolerance:±5%
- Current Rating (Amps):30 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):28Ohm Max
- Q @ Freq:8 @ 796kHz
- Frequency - Self Resonant:1.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210
- Size / Dimension:0.138" L x 0.114" W (3.50mm x 2.90mm)
- Height - Seated (Max):0.089" (2.25mm)
