B78148S1392K000

Technical Details

• Series:BC
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:3.9 µH
• Tolerance:±10%
• Current Rating (Amps):850 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):310mOhm Max

• Q @ Freq:60 @ 7.96MHz
• Frequency - Self Resonant:105MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:7.96 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Radial
• Supplier Device Package:-
• Size / Dimension:0.157" Dia x 0.362" L (4.00mm x 9.20mm)
• Height - Seated (Max):-
