AISC-0603F-R50J-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 500NH 410MA 450 MOHM
- CategoryFixed Inductors
- Datasheet AISC-0603F-R50J-T Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.13824
- 6,000$0.13824
Quote It
Technical Details
- Series:AISC-0603F
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:500 nH
- Tolerance:±5%
- Current Rating (Amps):410 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):450mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:610MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.039" W (1.60mm x 1.00mm)
- Height - Seated (Max):0.047" (1.20mm)
