NRH3010T150MNV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 450MA 660 MOHM
- CategoryFixed Inductors
- Datasheet NRH3010T150MNV Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$0.15246
- 2,000$0.15246
Quote It
Technical Details
- Series:NR, H Type
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):450 mA
- Current - Saturation (Isat):450mA
- Shielding:Shielded
- DC Resistance (DCR):660mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:25MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.039" (1.00mm)
