PE-0805CD100GTT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10.2NH 600MA 140 MOHM
- CategoryFixed Inductors
- Datasheet PE-0805CD100GTT Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$0.1395
- 10,000$0.1395
Quote It
Technical Details
- Series:0805CD
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:10.2 nH
- Tolerance:±2%
- Current Rating (Amps):600 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):140mOhm Max
- Q @ Freq:50 @ 500MHz
- Frequency - Self Resonant:4.1GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.090" L x 0.066" W (2.29mm x 1.68mm)
- Height - Seated (Max):0.062" (1.58mm)
