TYS3015220M-10
Laird - Performance Materials
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 570MA 460 MOHM
- CategoryFixed Inductors
- Datasheet TYS3015220M-10 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$0.13558
- 20,000$0.13558
Quote It
Technical Details
- Series:TYS3015
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):570 mA
- Current - Saturation (Isat):520mA
- Shielding:Shielded
- DC Resistance (DCR):460mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:23MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.067" (1.70mm)
