B82141A1103K009

Technical Details

• Series:SBC
• Package:Tape & Box (TB)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:10 µH
• Tolerance:±10%
• Current Rating (Amps):410 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):600mOhm Max

• Q @ Freq:55 @ 2.52MHz
• Frequency - Self Resonant:25MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:2.52 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.118" Dia x 0.268" L (3.00mm x 6.80mm)
• Height - Seated (Max):-
