SRN4012T-3R3M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 1.7A 70 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN4012T-3R3M Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$0.1428
- 4,500$0.1428
- 9,000$0.1344
- 13,500$0.1302
- 31,500$0.126
Quote It
Technical Details
- Series:SRN4012T
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):1.7 A
- Current - Saturation (Isat):1.4A
- Shielding:Semi-Shielded
- DC Resistance (DCR):70mOhm
- Q @ Freq:6 @ 100kHz
- Frequency - Self Resonant:60MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.047" (1.20mm)
