B78148S1475J009
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7MH 55MA 78 OHM TH
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$0.1432
Quote It
Technical Details
- Series:BC
- Package:Tape & Box (TB)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite Drum
- Inductance:4.7 mH
- Tolerance:±5%
- Current Rating (Amps):55 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):78Ohm Max
- Q @ Freq:35 @ 252kHz
- Frequency - Self Resonant:700kHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial
- Supplier Device Package:-
- Size / Dimension:0.157" Dia x 0.362" L (4.00mm x 9.20mm)
- Height - Seated (Max):-
