PM0805-R15K-RC

Technical Details

• Series:PM0805
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Alumina
• Inductance:150 nH
• Tolerance:±10%
• Current Rating (Amps):400 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):670mOhm

• Q @ Freq:50 @ 250MHz
• Frequency - Self Resonant:950MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0805 (2012 Metric)
• Supplier Device Package:0805 (2012 Metric)
• Size / Dimension:0.083" L x 0.059" W (2.10mm x 1.50mm)
• Height - Seated (Max):0.059" (1.50mm)
