PM0805-R18K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 180NH 350MA 850MOHM SM
- CategoryFixed Inductors
- Datasheet PM0805-R18K-RC Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$0.144
- 2,000$0.144
Quote It
Technical Details
- Series:PM0805
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Alumina
- Inductance:180 nH
- Tolerance:±10%
- Current Rating (Amps):350 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):850mOhm
- Q @ Freq:50 @ 250MHz
- Frequency - Self Resonant:900MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.083" L x 0.059" W (2.10mm x 1.50mm)
- Height - Seated (Max):0.059" (1.50mm)
