AIUR-03-102K

Technical Details

• Series:AIUR-03
• Package:Bulk
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1 mH
• Tolerance:±10%
• Current Rating (Amps):220 mA
• Current - Saturation (Isat):290mA
• Shielding:Unshielded
• DC Resistance (DCR):2.9Ohm Max

• Q @ Freq:50 @ 252kHz
• Frequency - Self Resonant:1.3MHz
• Ratings:-
• Operating Temperature:-25°C ~ 85°C
• Inductance Frequency - Test:252 kHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Radial, Vertical Cylinder
• Supplier Device Package:-
• Size / Dimension:0.354" Dia (9.00mm)
• Height - Seated (Max):0.472" (12.00mm)
