B82144A2475J009

Technical Details

• Series:LBC
• Package:Tape & Box (TB)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:4.7 mH
• Tolerance:±5%
• Current Rating (Amps):90 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):20Ohm Max

• Q @ Freq:60 @ 252kHz
• Frequency - Self Resonant:500kHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.205" Dia x 0.472" L (5.20mm x 12.00mm)
• Height - Seated (Max):-
