SDR0603-7R5ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 7.5UH 1.29A 120MOHM SM
- CategoryFixed Inductors
- Datasheet SDR0603-7R5ML Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.2431
- 1,200$0.2275
Quote It
Technical Details
- Series:SDR0603
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:7.5 µH
- Tolerance:±20%
- Current Rating (Amps):1.29 A
- Current - Saturation (Isat):1.6A
- Shielding:Unshielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:19 @ 7.96MHz
- Frequency - Self Resonant:38MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.228" L x 0.228" W (5.80mm x 5.80mm)
- Height - Seated (Max):0.154" (3.90mm)
