AIUR-05-151K
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 460MA 400 MOHM
- CategoryFixed Inductors
- Datasheet AIUR-05-151K Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.2448
- 10$0.2142
- 100$0.153
- 500$0.12852
- 1,000$0.10404
- 2,500$0.09792
Quote It
Technical Details
- Series:AIUR-05
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:150 µH
- Tolerance:±10%
- Current Rating (Amps):460 mA
- Current - Saturation (Isat):610mA
- Shielding:Unshielded
- DC Resistance (DCR):400mOhm Max
- Q @ Freq:10 @ 796kHz
- Frequency - Self Resonant:4.3MHz
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.354" (9.00mm)
