LQH43MN180J03L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 340MA 820 MOHM
- CategoryFixed Inductors
- Datasheet LQH43MN180J03L Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.24612
- 500$0.24612
Quote It
Technical Details
- Series:LQH43
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±5%
- Current Rating (Amps):340 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):820mOhm Max
- Q @ Freq:35 @ 1MHz
- Frequency - Self Resonant:17MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.110" (2.80mm)
