NRS6012T1R5NMGGV

Technical Details

• Series:NR, S Type
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.5 µH
• Tolerance:±30%
• Current Rating (Amps):2.1 A
• Current - Saturation (Isat):2.6A
• Shielding:Shielded
• DC Resistance (DCR):80.4mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:69MHz
• Ratings:AEC-Q200
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
• Height - Seated (Max):0.047" (1.20mm)
