LQH43CN2R7M33L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7UH 1.8A 69 MOHM SMD
- CategoryFixed Inductors
- Datasheet LQH43CN2R7M33L Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$0.26306
- 500$0.26306
Quote It
Technical Details
- Series:LQH43
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 µH
- Tolerance:±20%
- Current Rating (Amps):1.8 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):69mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:50MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812 (4532 Metric)
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.110" (2.80mm)
