82332C

Technical Details

• Series:8200
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:-
• Inductance:3.3 µH
• Tolerance:±20%
• Current Rating (Amps):950 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):138mOhm Max

• Q @ Freq:18 @ 1MHz
• Frequency - Self Resonant:67MHz
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:10 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1210 (3225 Metric)
• Supplier Device Package:1210
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
• Height - Seated (Max):0.091" (2.30mm)
