AIAC-1812-33NK-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33NH 3A 5.9 MOHM SMD
- CategoryFixed Inductors
- Datasheet AIAC-1812-33NK-T Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$0.26112
- 2,000$0.26112
- 4,000$0.24576
- 6,000$0.23808
- 10,000$0.2304
Quote It
Technical Details
- Series:AIAC-1812
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:33 nH
- Tolerance:±10%
- Current Rating (Amps):3 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):5.9mOhm Max
- Q @ Freq:100 @ 150MHz
- Frequency - Self Resonant:2.5GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:150 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.185" L x 0.138" W (4.70mm x 3.50mm)
- Height - Seated (Max):0.146" (3.70mm)
