RLH0912-6R8ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 2.5A 28 MOHM TH
- CategoryFixed Inductors
- Datasheet RLH0912-6R8ML Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$0.2618
- 1,000$0.245
Quote It
Technical Details
- Series:RLB
- Package:Tube
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):28mOhm Max
- Q @ Freq:30 @ 7.96MHz
- Frequency - Self Resonant:33MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.343" Dia (8.70mm)
- Height - Seated (Max):0.433" (11.00mm)
