CDRH3D11HPNP-2R2NC

Technical Details

• Series:CDRH3D11/HP
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:-
• Material - Core:Ferrite
• Inductance:2.2 µH
• Tolerance:±25%
• Current Rating (Amps):1.15 A
• Current - Saturation (Isat):1.6A
• Shielding:Shielded
• DC Resistance (DCR):143mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.150" L x 0.150" W (3.80mm x 3.80mm)
• Height - Seated (Max):0.047" (1.20mm)
