0420CDMCCDS-100MC

Technical Details

• Series:0420CDMC/DS
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Molded
• Material - Core:Metal
• Inductance:10 µH
• Tolerance:±20%
• Current Rating (Amps):1.5 A
• Current - Saturation (Isat):2.5A
• Shielding:Shielded
• DC Resistance (DCR):282mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:SMD
• Size / Dimension:0.173" L x 0.165" W (4.40mm x 4.20mm)
• Height - Seated (Max):0.079" (2.00mm)
