CDRH5D28NP-180NC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 1A 110 MOHM SMD
- CategoryFixed Inductors
- Datasheet CDRH5D28NP-180NC Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$0.289
- 2,000$0.289
Quote It
Technical Details
- Series:CDRH5D28
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±30%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):110mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.224" L x 0.224" W (5.70mm x 5.70mm)
- Height - Seated (Max):0.118" (3.00mm)
