PM105SB-390L-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 39UH 1.1A 120 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM105SB-390L-RC Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$0.4704
- 500$0.44982
- 1,000$0.39984
- 2,500$0.39102
Quote It
Technical Details
- Series:PM105SB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:39 µH
- Tolerance:±15%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:31 @ 2.52MHz
- Frequency - Self Resonant:14MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.390" L x 0.390" W (9.90mm x 9.90mm)
- Height - Seated (Max):0.189" (4.80mm)
