ASPI-0310FS-100M-T2
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 900MA 350 MOHM
- CategoryFixed Inductors
- Datasheet ASPI-0310FS-100M-T2 Datasheet
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
- 1$0.47616
- 2,000$0.47616
Quote It
Technical Details
- Series:ASPI-0310FS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Nickel Zinc Ferrite (NiZn)
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):900 mA
- Current - Saturation (Isat):600mA
- Shielding:Shielded
- DC Resistance (DCR):350mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-25°C ~ 120°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.039" (1.00mm)
