RCP1317NP-470M
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 3.3A 69 MOHM TH
- CategoryFixed Inductors
- Datasheet RCP1317NP-470M Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$0.522
- 500$0.522
Quote It
Technical Details
- Series:RCP1317
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±20%
- Current Rating (Amps):3.3 A
- Current - Saturation (Isat):4.3A
- Shielding:Shielded
- DC Resistance (DCR):69mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.531" Dia (13.50mm)
- Height - Seated (Max):0.689" (17.50mm)
