SRR1208-181YL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 180UH 1.2A 270MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1208-181YL Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$0.5236
- 400$0.4998
- 800$0.4046
- 1,200$0.3808
- 2,800$0.3724
Quote It
Technical Details
- Series:SRR1208
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:180 µH
- Tolerance:±15%
- Current Rating (Amps):1.2 A
- Current - Saturation (Isat):1.7A
- Shielding:Shielded
- DC Resistance (DCR):270mOhm Max
- Q @ Freq:14 @ 796kHz
- Frequency - Self Resonant:2.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.500" W (12.70mm x 12.70mm)
- Height - Seated (Max):0.335" (8.50mm)
